UPS Armac Office 1000VA 650W 230V, 3xSchuko/ LCD/Metal Case
Производител:
NATEC
Шифра: 29393306
Достапност:
Шифра: 29393306
Достапност:
Редовна Цена:
5,980 ден.
На 24 рати x 249 ден.
Capacity 40k VA / 40k W
Type On-line
Input Nominal Voltage 3 x 400 VAC (3Ph+N)
Voltage range 190-520 VAC (3-phase) @ 50% load
305-478 VAC (3-phase) @ 100% load Frequency Range 46 ~ 54Hz
Phase 3 Phases IN / 3 Phases OUT Power Factor ≥ 0.99 at 100% load
Outlet type Terminal Block Wiring
Output
Nominal Voltage 3 x 360*/380/400/415 VAC (3Ph+N)
AC Voltage Regulation
(Batt. Mode) ± 1% Frequency Range (Synchronized Range)
46 ~ 54Hz Frequency Range
(Batt. Mode) 50Hz ± 0.1 Hz
Current Crest Ratio 3:1 (max.)
Harmonic Distortion ≤ 2 % THD (Linear Load)
≤ 5 % THD (Non-linear Load)
Waveform (Batt. Mode) Pure Sine-wave
Outlet type Terminal Block Wiring
Transfer Time
AC Mode to Batt. Mode Zero
Inverter to Bypass Zero
Overload
AC Mode 100-110% for 60 min
110-125% for 10 min
125%~150% for 1 min
>150% immediately
Battery Mode 100-110% for 60 min
110-125% for 10 min
125%~150% for 1 min
>150% immediately
Efficiency
AC Mode = 95.5 % with fully charged batteries
Battery Mode = 94.5 % with fully charged batteries
ECO Mode = 98.5 % with fully charged batteries
Battery
Internal batteries
(optional)
32~80 pieces of 12V lead acid
7Ah or 9Ah
External batteries 12V lead acid,
(N + N) pcs x 1~2 strings;
N=16~20
Charging Voltage +/-13.65V*N; N=16~20
Charging Current (max) 1A-12A (adjustable)
Environment
Humidity < 95 % RH at 0-40єC
(non-condensing)
Noise level Less than 70dB at 1 m
Heat dissipation up to 6844 BTU/h (line mode)
up to 9181 BTU/h (battery mode)
Management
Communication ports RS232 / USB / EPO / SNMP /
Modbus / AS400 (cards optional)
Software compatibility ViewPower Network Edition and
VMWare Shutdown Wizard
